Application

Compatible for Audi A6 C7 (4G2,4GC) 3.0 Tdi Quattro 230KW 2011-2018
compatible for Audi A6 Allroad C7 (4GH,4GJ) 3.0 Tdi Quattro 230KW 2012-2014
compatible for Audi A6 C7 Avant (4G5,4GD) 3.0 Tdi Quattro 230KW 2011-2018
compatible for Audi A7 Sportback (4GA,4GF) 3.0 Tdi Quattro 230KW 2011-2015
compatible for Audi Q5 (8RB) SQ5 Tdi Quattro 230KW 2012-2015

OE/Part number

805713-5004S, 805713-0004, 805713-4,
805716-0007, 805716-5007S, 805716-7,
805713-5007S, 805713-0007, 805713-7,
805713-5008S, 805713-0008, 805713-8,
805713-5009S, 805713-0009, 805713-9,
059145061L, 059145061AD, 059145061Q,
059145061T, 059145061AL, 059145061QX,
059145061TX, 059145653LX, 059145654HX,
059145654LX, 059145061QV, 059145061TV,
059145653LV, 059145654HV, 059145654LV

Specification

Turbo Model: GTB1749VK
Engine Code: BiTDI Quattro Euro 5
Color: Silver
Cooling Type: Water+Oil Cooling
Features：Individual
Universal Fitment: No
Condition: 100% Brand New
Accessories: You will get what you can see in the pictures exactly

Feature

* Product
1. OEM-quality and size
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer

Note

* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
* Please confirm your original turbo PART NUMBER before Purchasing.
* Professional installation is highly recommended,
* Before installation, please check the oil supply sufficient, clearnliness the air filter and gasoline , and the gasoline air tightness.
